Zimmer Group MKS2501A Pneumatic Profile Rail Clamp NC 750N PLUS 1400N:
$279.90

The MKS2501A is designed for clamping applications where secure holding is required in the event of a loss of energy or air pressure. Pneumatic activation releases the clamp, while a PLUS air connection can provide increased holding force.

The clamping mechanism uses a wedge-type gear to transfer force from the pneumatic piston to the clamping jaw. The clamping jaw presses against the free surfaces of the profile rail guide.

The manufacturer specifies a 750 N holding force, increasing to 1,400 N with the PLUS connection. The unit is rated for 5,000,000 static clamping cycles.

Features

Genuine Zimmer Group clamping element
Model / Order No.: MKS2501A
Pneumatic operation
Designed for common profile rail guides
Normally Closed (NC) configuration
Closes without pneumatic pressure
Spring-loaded energy storage
Safety clamping in case of energy failure
Standard holding force: 750 N
PLUS connection holding force: 1,400 N
PLUS air connection available
High durability
Rated for 5 million static clamping cycles
Wedge-type gear power transmission
Pneumatic piston-operated
Positioning accuracy: ±0.02 mm
Fast opening and closing times
Suitable for clean-room applications
CE / UKCA / LABS / REACH / RoHS certifications GroupModelMKS2501AOrder NumberMKS2501ATypePneumatic Clamping ElementApplicationProfile Rail Guide – Normally ClosedClosing Without PressureYesStandard Holding Force750 NTheoretical Holding Force, μ=0.1938 NPLUS ConnectionYesHolding Force with PLUS1,400 NOperating Pressure5.5–6.5 barNominal Operating Pressure6 barB10d Value5,000,000Positioning Accuracy±0.02 mmOpening Time0.02 secClosing Time0.015 secOperating Temperature-10 to +70°CWeight0.4 kg / approx. 0.88 lbAir Volume per Cycle9 cm³Installation DirectionFrom aboveClean Room RatingISO 14644-1 Class 6CertificationsCE / UKCA / LABS / REACH / RoHS
All of the above specifications are taken from the supplied Zimmer Group product document.
Technical Construction
The MKS2501A consists of:
1. Profile rail guide interface — designed for common profile rail guides.
2. Wedge-type gear — transfers force between the pneumatic piston and clamping jaw.
3. Clamping jaw — presses against the free surfaces of the profile rail guide.
4. Housing
5. Pneumatic piston — moves the wedge mechanism longitudinally.
6. Spring-loaded energy storage — closes the clamping unit when it is not pressurized.
Important Installation Information
The manufacturer states that the element does not provide guiding properties; external guidance is required. The holding force is the maximum force that can be applied in the axial direction. The unit is tested for its specified holding force on a hardened steel rail with a lightly oiled ISO-VG 68 lubricating layer. Different lubricants or rail coatings can affect the coefficient of friction and therefore the holding force.
