VIAVI OneExpert ONX-610 CATV Sweep Kit NSC-100 + 2x WFED-300AC + Chargers:
$749.99

VIAVI OneExpert ONX-610 CATV Sweep Kit NSC-100 + 2x WFED-300AC + Chargers

DOCSIS 3.1 | 65/200 MHz High-Split | Fwd/Rev Sweep | SWX NTX TSX Enabled

Item description

VIAVI / JDSU OneExpert ONX-610 CATV field kit with Network & Service Companion (NSC-100) and two WFED-300AC WiFi Advisor units. Includes power supplies. Used working field equipment. Photos show the exact units offered.

This is not a basic install meter. The installed CATV module is a sweep-capable high-split unit, and the software list includes forward sweep, reverse sweep, sweepless sweep, reverse alignment, SWX, NTX, TSX, IPX, Ingress Expert, DOCSIS 3.1 OFDM, 32x8 bonding, Ookla Speedtest, and VoIP.

What’s included

1x VIAVI OneExpert ONX-610 handheld
1x VIAVI ONX-CATV-D31-S-6520-1212 CATV module (installed)
1x VIAVI Network & Service Companion NSC-100
2x JDSU / VIAVI WFED-300AC WiFi Advisor analyzers
Fitted JDSU / VIAVI holster for the meter
All power supplies / chargers for the included instruments

Do not assume extra F-cables, Ethernet leads, SFPs, or a tablet unless shown in the photos.

ONX-610 identification (from the unit screens)

Meter model: ONX-610
Software bundle: ONXCBL.4.12.17
Base: 10.12.17
Cable: 4.12.17
DOCSIS Cable Modem 3390: 1.7.928
Unit ID: ARQA0001150014
Assembly ID: 22089324
Ethernet MAC: 00:07:11:1B:D5:72
System MAC: 00:07:11:1B:D5:73
Test 1 MAC: 00:07:11:1B:D5:74
CATV module: ONX-CATV-D31-S-6520-1212
Module serial: RRQW0052170680
Battery shown at about 89–90% in the photos

Hardware options shown

DOCSIS 3.1 hardware capable
Low/high diplexers: 65/200 MHz – 1.2/1.2 GHz
Ingress scan range: 4–204 MHz
Sweep capable
Field View capable
MoCA 2.0 bonding capable
Port 2 clamping
Wi-Fi region: (1) ETSI
Wi-Fi country: DE
HL leakage capable
Large flash
Digital hum capable
Video analysis capable

Software shown as Enabled

Ingress Expert
IPX Package
NTX Package
ONX Bluetooth SW Opt
ONX DOCSIS 3.1 OFDM
ONX DOCSIS 32x8 Bonding
ONX Forward Sweep
ONX Reverse Sweep
ONX Mobile SW Opt
Ookla Speedtest
Reverse Alignment
Sweepless Sweep
SWX Package
TSX Package
VoIP

Software shown as Upgradeable (not enabled)

Database Mining, Field View, Field View with RSG, HL Leakage, Home TDR, ONX IP Video, ONX MoCA, ONX QAM Video, ONX Reverse Sweepless Sweep, OneCheck Expert, OneCheck WiFi, RSG Loopback, RSG TX, Rapid Reverse Sweep, Return Path SNR, SmartAccess Anywhere, TrueSpeed, VoIP MOS.

What this kit does

High-split / mid-split HFC work with 65/200 MHz diplexers and 1.2 GHz forward range
DOCSIS 3.1 OFDM and 32x8 bonding tests
Forward sweep, reverse sweep, sweepless sweep, and reverse alignment
Ingress Expert plus IPX / NTX / TSX / SWX feature sets already on
Ethernet / service-layer companion testing with the NSC-100
Dual-puck Wi-Fi Advisor site assessment with two WFED-300AC units (802.11ac, 2.4/5 GHz, up to 3x3)

Important buyer notes

Chassis is an ONX-610, not an ONX-620 or ONX-630. The 610 uses the smaller 48 WHr battery (about 3–4 hours continuous / 7–10 hours typical). The 620/630 use the larger 96 WHr pack.
Wi-Fi region is ETSI and country code is DE. Confirm that matches your market before buying if you need FCC/US Wi-Fi operation.
Sweep licenses are enabled, but Field View software, Home TDR, TrueSpeed, and VoIP MOS are still listed as upgradeable.
No claim of current factory calibration or remaining VIAVI warranty.

Condition

Used field gear. Meter powers on, screen is readable, and menus match the photos. Holster and bumpers show normal truck wear. One WFED is labeled “A.” Sold as a used working kit as pictured.

Questions welcome. Extra photos available on request.
