On eBay Now...Burndy Bisr250db Insulated Multitap Connector Splice Direct Burial BISR250 For Sale
When you click on links to various merchants on this site and make a purchase, this can result in this site earning a commission. Affiliate programs and affiliations include, but are not limited to, the eBay Partner Network.
Burndy Bisr250db Insulated Multitap Connector Splice Direct Burial BISR250:
$49.98
SpecificationsProduct InformationMFR #BISR250DBZoro #G4667695UPC #781810555316Country of OriginUnited StatesDimensionsFor Wire Size250 kcmilHex Size5/16 inMin. Conductor Size4/0Stud Size5/16 inWidth2.17 inLength6.7 inMax. Conductor Size250 kcmilLength (Straight Wireway)6.7 inOverall Width1.18 inOverall Length6.7 inFor Stranded Copper Wire Size - Minimum4/0 AWGFor Stranded Copper Wire Size - Maximum250 kcmilStrip Length7/8 inConductor Size4/0 AWG-250 KCMILConductor - Copper Str Size Range4/0 - 250 StrDimension - Strip Length inch7/8 inConductor - Copper Str Size4/0 AWG;250 kcmilDimension - L Length Overall mm170.18 mmConductor - AL Str Size Range4/0 - 250 StrDimension - Screw Size inch45054Dimension - Height inch2.17 inDimension - Width inch1.18 inDimension - Width mm29.97 mmConductor - AL Str Size4/0;250 kcmilDimension - Length Overall inch6.7 inDetailsItemInsulated Multitap ConnectorConnector TypeDouble-Sided EntryNumber of Ports2For Conductor MaterialAluminum, CopperBody MaterialAluminumInsulation MaterialPlastisolDirect Burial RatedYesTorque360 in-lbHead StyleHexFinishUnplatedColorRedMaximum Operating Temperature194 Degrees FStandardsUL 486A, UL 486B, UL ListedNo. of Ports2Screw MaterialAluminumMax. Voltage600V AC/DCMaterialAluminumTap ShapeTSpecial FeaturesInsulated, Oxide Inhibitor Pre-Installed Preventing Moisture and Contaminants From Entering Contact Area, Saves TimeRoHS CompliantYesMaximum Voltage600 VTypeBISRStandards - Industry Standards MetUL468A-468BVoltage - Maximum600 VItem Type3BTemperature Rating90 °CHex Key5/16 inCertification - CSA ApprovedNoApplicationFor Outside Direct BurialConductor TypeAL C Str-SizeCU C Str-SizeOperating Voltage600 VRating - Minimum Voltage600Installation Torque Recommended in-lb360 in-lbTrade NameUNITAP™InsulationYIndustry Standard(s)UL468A-468BPlating TypeUnplatedUL ListedYesPhysical Attribute - Number of Screws2Insulation TypePlastisolCertification - UL Listed Direct BurialYesPlatedNPhysical Attribute - Screw TypeAllen
Burndy Bisr250db Insulated Multitap Connector Splice Direct Burial BISR250
$49.98
Burndy Bisr1db Insulated Multitap Connector,6.30 In. W
$76.26
Burndy Bisr250db Insulated Multitap Connector Splice Direct Burial BISR250 (1pc)
$49.99
