Office/Restaurant/Cafe/Bar Audio Package w/6) JBL drop Ceiling Tile Speakers+Amp For Sale

When you click on links to various merchants on this site and make a purchase, this can result in this site earning a commission. Affiliate programs and affiliations include, but are not limited to, the eBay Partner Network.

Office/Restaurant/Cafe/Bar Audio Package w/6) JBL drop Ceiling Tile Speakers+Amp:
$1029.80

Car Audio & VideoPro AudioMarine AudioLightingKaraokeHome/Portable Audio

Package: Rockville RCS80-1 60 Watt 70v Commercial Restaurant Amplifier/Receiver with Bluetooth + (3) Pairs of JBL LCT 81C/T Commercial Drop Ceiling Tile Speakers For Office/Restaurant/Cafe

Click Thumbnails to EnlargeCondition and Warranty

Condition: BRAND NEW IN ORIGINAL PACKAGING

Warranty: 1 YEAR AUDIOSAVINGS

Product DescriptionPackage Includes:

(1) JBL VMA160 60-Watt 70 Volt 70V Mixer/Amplifier with Bluetooth 5 Channel Inputs
(3) Pair of JBL LCT 81C/T Commercial Drop Ceiling Tile Speakers For Office/Restaurant/Cafe

Authorized JBL Dealer!

Description:

The JBL VMA Series is a cost-effective line of Mixer/Amplifiers with low impedance functionality (4O, 8O) and high impedance 70V and 100V output. They are designed with convenient and flexible features to be used by commercial integrators worldwide, ideal for emerging markets.

Features:

JBL VMA160 60 Watt 70V Mixer/Amplifier with Bluetooth and 5 Channel Inputs
Max Output Power: 60 Watts
Frequency Response: 20 Hz - 20 kHz
THD (Total Harmonic Distortion): <0.5%
Signal-to-Noise Ratio: > 76 dB
Input Impedance: Mic: 400 Ohms Line: 20 kOhms (balanced) RCA: 50 kOhms
Phantom Power: 27VDC
Crosstalk: -70 dB
Nominal AC Line Voltages: 100V, 120V, 220V, 220-240V, 50/60 Hz
Minimum Load Impedance: 4 Ohms, 80 Ohms,160 Ohms
Insertion Loss: 1 dB Maximum
Number of Inputs: 5
Number of Outputs: 1
Tone Control: Bass +/-14dB @ 50Hz; Treble +/-14dB @10kHz
Input Sensitivity: Mic Input: 5.5mVRMS Line Input: 1.3VRMS RCA Input (stereo in): 130mVRMS
Independent bass and treble controls for each output channel
Paging Chime, and Priority Muting
Rack mounting hardware included
Product Dimensions (W x D x H): 17" x 16.3" x 3.5" inches
Product Weight: 19.4 Lbs.

All About Your 70 Volt:

Description:

Low-Profile Lay-In 2' x 2' Ceiling Tile Loudspeaker with 200 mm (8 in) Driver
LCT 81C/T is a full-range ceiling speaker designed to lay into a 2 ft x 2 ft US-style suspended grid ceiling, with no cutting of ceiling tiles required, making for an easy and cost-effective installation with a minimum of mess. The low profile depth of only 100 mm (4 in) allows the speaker to fit in locations where deeper loudspeakers do not.This loudspeaker is designed to provide excellent performance for paging and light-to-medium music in a wide variety of applications, including education classrooms, business music systems, retail stores, music/paging systems, airports, reception/waiting rooms, lounges, courtrooms, meeting rooms, and more.The very high sensitivity of 96 dB provides maximum sound level, even at low tap settings. LCT 81C/T contains a 200 mm (8 in) dual-cone driver with a very high 96 dB sensitivity. The driver features a 25 mm (1 in) diameter voice coil with a Kapton coil-former and high-temperature wire for better power dissipation and long-term reliability. The speaker's built-in 10 Watt transformer provides versatility by allowing use on 100V or 70V distributed loudspeaker lines, as well as at 8 ohms (low impedance) for driving directly from a low impedance power amplifier. Adjusting is convenient via a rotary switch on the side of the rear enclosure. Two safety seismic attachment tabs are provided for securing to ceiling deck, plus 4 holes are provided -- one in each corner. The color of the perforated grille is white.

Features:

High efficiency 200 mm (8 in) dual-cone driver.
Easy lay-in installation into 2' x 2' US-style suspended grid ceilings. No cutting of ceiling tiles is necessary.
Perforated metal grille included.
Combined 70V/100V and low impedance direct operation.
20 Watts at 8O (low-impedance) direct setting.
10 Watt multi-tap at 70V/100V with taps at 10W, 5W, 2.5W (and 1.3W for 70V only)
Very low-profile at just 103 mm (4.1 in) deep, to fit into ceilings that are shallow or that contain obstructions.
Easy bare-wire connection in protected compartment. Wire entrance from either top or side via knock-out.
Very high 96 dB sensitivity turns power from small amplifiers into maximum sound level for listeners.
Designed for high speech intelligibility.
100° coverage pattern (conical).
UL1480A and UL2043 certifications for use in ceiling plenum
Transducer: High-efficiency 200 mm (8 inch) dual-cone driver with 25 mm (1 in) diameter voice coil, Kapton coil former, and high-temperature voice coil wire.
Frequency Range (-10 dB): 100 Hz – 16 kHz
Nominal Sensitivity: 96 dB
Nominal Coverage Angle: 100° conical coverage (ave. 1 kHz - 4 kHz)
Rated Maximum SPL: 108 dB @ 1 m (3.3 ft) average, 108 dB peak (at 8O setting)
Nominal Impedance: 8 ohms (in Direct/Thru 8O setting)
Transformer Taps: 10 W, 5 W, 2.5 W @ 70V or 100V (plus 1.3 W @ 70V only)
Recommended Protective High Pass: 90 Hz high-pass (24 dB/oct) for 8O direct or any 70V or 100V tap setting
Power Capacity (at low-Z):
40 Watts Continuous Program Power
20 Watts Continuous Pink Noise
Input Connector: Bare wire inside protected in touch-proof wiring compartment.
Tap Selector: Rotary switch accessible from side of backcan
Materials: Steel rear enclosure, front baffle, and perforated grille
Grille Color: White
Safety Agency: Suitable for use in air handling spaces certified per UL1480A, Speakers for Commercial and Professional Use; UL2043, Standard for Fire Test for Heat and Visible Smoke Release for Discrete Products Installed in Air Handling Spaces; NFPA90 & NFPA70; S7232/UL Listed, Signaling Speaker.
Dimensions: 607 x 607 x 103 mm (23.9 x 23.9 x 4.1 in)
Net Weight: 7.1 kg (15.7 lbs)
Shipping Weight: 8.3kg ea; 16.5 kg per pair-pack (18.3 lbs ea; 36.4 lbs per pair-pack)
Ceiling Cutout Size: No cutout required. Speaker drops into ceiling grid
Suspension / Safety-Seismic: Attachment Points Two tabs on back baffle, plus 4 holes in corners
