New Sealed in box Lenel/Security 2 S2-INP-Input Blade:
$175.00

Key Capabilities

8 Configurable Input Points: Provides 8 software-configurable inputs that support Normally Open (NO), Normally Closed (NC), supervised, and non-supervised circuits.
Quad-State Supervision: Supports full Quad-State monitoring (Open, Short, Normal, Alarm) utilizing $1\text{k}\Omega$ End-of-Line (EOL) resistors.
Plug-and-Play Discovery: Automatically recognized and addressed by the LenelS2 Network Node via ribbon bus cable—no DIP switches or manual jumpers required.
High System Capacity: Up to 7 application blades (in any combination of S2-ACM, S2-INP, S2-OUTP, or S2-TEMP) can be installed inside a single S2 NetBox or Network Node enclosure.

Technical SpecificationsFeatureSpecificationPart NumberS2-INPInput Quantity8 monitored inputsInput Supervision ModesQuad-State, Dual Resistor, Single Series, Single Parallel, UnsupervisedResistor Values$1\text{k}\Omega$ EOL ResistorsPower Input12 VDC (supplied directly via ribbon cable connection from Network Node)Max BTU Rating20 BTU/hrDimensions$7.5'' \times 4.0'' \times 0.83''$ ($191\text{ mm} \times 102\text{ mm} \times 21.1\text{ mm}$)Weight4.5 oz (127 g)Operating Temp$32^\circ\text{F}$ to $95^\circ\text{F}$ ($0^\circ\text{C}$ to $35^\circ\text{C}$)Cabling Requirement22 AWG twisted, shielded cable (Belden #9462 or equivalent)Max Cable Distance2,000 ft (610 m) per input runCertificationsUL 294, CE, RoHSSupported Input Devices & Use Cases

Door Status Switches: Door Position Switches (DPS) and Door Status Monitors (DSM).
Request to Exit (REX): PIR motion detectors, panic buttons, and manual egress switches.
Facility Security: Beam detectors, glass break sensors, motion sensors, and burglar alarm panel outputs.
System Infrastructure: Power supply fault contacts, low battery signals, and tamper switches.

Compatibility

Fits available expansion slots across the following LenelS2 hardware platforms:
