CAMPBELL HAUSFELD UNIVERSAL PRESSURE SWITCH FP073600AV AIR COMPRESSOR PARTS:
$18.65
Brand New !!!
THIS PRESSURE SWITCH WILL EXACTLY REPLACE CAMPBELL HAUSFELD FP073600AVTHIS IS NOT AN OEM CAMPBELL HAUSFELD PRODUCT
THIS IS A BRAND NEW LeFOO PRESSURE SWITCH 95-125 WITH 4 WAY MANIFOLD.
THIS SWITCH REPLACES FURNAS... SQUARE D ... ANDMOST OTHER PRESSURE SWITCH MANUFACTURERS.
THIS SWITCH COMES WITH AN UNLOADER, ON/OFF LEVER AND 4 WAY MANIFOLD.
THE 4 WAY MANIFOLD GIVES YOU THE OPTION OF CONNECTING 3 ADDITIONAL ACCESSORIES TO YOUR PRESSURE SWITCH. FOR EXAMPLE,1/4" GAUGE, SAFETY VALVE, OR REGULATOR INTO THE 1/4" MANIFOLD CONNECTIONS. THE UN-USED CONNECTION PORTS CAN BE PLUGGED.
PRESSURE: 95-125
MAX PRESSURE: 150 PSI
MIN PRESSURE: 35 PSI
DIFFERENTIAL: 35-55 PSI
PORT: 1/4" (NPT) 4 PORT FEMALE
POLE: 2 POLE RATING
AMP RATING: Recommended 18 amp MAX, without the use of a magnetic starter.
