Allen-Bradley MicroLogix 1500 1764-28BXB Base + 1764-LRP Processor + 1769-ECR:
$250.00

Allen-Bradley MicroLogix 1500 PLC - 3 pieces

• 1764-28BXB base unit (24 VDC power)
• 1764-LRP processor
• 1769-ECR right end cap / terminator

CONDITION

Used - in good working condition when removed from service. Normal light wear on the housing - please see the base: 24 VDC power, 16 DC inputs (24 V sink/source), 12 outputs (6 relay + 6 DC FET)

1764-LRP processor: enhanced MicroLogix 1500 processor with a second built-in RS-232 port (Channel 1)

Channel 0 mini-DIN serial port on the base

1769-ECR end cap included, so you can run it right away or add Compact I/O

Programmed with RSLogix 500 / RSLogix Micro

WHAT'S INCLUDED

• Base, processor and end cap exactly as pictured
• No program, cables, software or manuals

SHIPPING

Packed carefully with foam. Ships within 1 business day.

Questions? Please message me before buying - happy to send more photos.

---

---

---
