3-in-1 Digital Pressure Gauge, Transmitter:
$359.00

Dwyer DPG-2043-in-1 Digital Pressure Gauge, Transmitter, and Switch, 0.25% Accuracy, 50 psi
The Dwyer DPG204 3-in-1 Digital Pressure Gauge, Transmitter, and Switch, 0.25% Accuracy, 50 psi has a precise ±0.25% full scale accuracy. The 4 digit digital display will reduce the potential for errors in readings by eliminating parallax error commonly produced with analog gauges. The DPG-204 is packaged in a durable extruded aluminum case designed to meet NEMA 4X (IP66). The unit is powered by 12-24 VDC/VAC and contains two alarm set points along with a 4-20 mA process output. A four-button keypad allows easy access to features. These features include backlight, peak and valley, auto zero and conversion of the pressure units.Product Features:

Pressure Range: 50.00 psi
Service: Liquids and non-combustible compatible gases
Wetted Materials: Type 316L SS
Housing: Black polycarbonate front & back cover, anodized aluminum extruded housing with recessed grooves, polycarbonate overlay, Buna-N O-rings, 316L SS sensor construction
Accuracy: 0.25% F.S. ±1 least significant digit. (Includes linearity, hysteresis, repeatability)
Pressure Limit: 2x pressure range for models 1000 psi
Temperature Limits: 0 to 158°F (0 to 70°C)
Process Connection: 1/4 in. male NPT
Display: 4 digit (.425" H x .234" W digits)
Size: 3.00" OD x 1.90" deep (not including cables)
Weight: 8.84 oz (275 g)
Switch Type: 2 SPDT Form C contacts
Switch Electrical Rating: 0.5 A @ 125 VAC resistive, 1 A @ 24 VDC
Switch Relay Differential: 1 least significant digit
Switch Electrical Connections: 3 ft (.91 m) cable
Switch Mounting Orientation: Mount in any position
Switch Set Point Adjustment: Via menu
Transmitter Temperature Limits: 0 to 158°F (0 to 70°C)
Transmitter Thermal Effect: Between 70 to 158°F = 0.016%/°F, Between 0 to 70°F = 0.026%/°F
Transmitter Power Requirements: 12-24 VAC +/- 20% 50-400 Hz, 12-24 VDC +/-20%
Transmitter Output Signal: 4-20 mA
Transmitter Loop Resistance: 600 ohms maximum
Transmitter Power Consumption: 0.8 W max
Transmitter Electrical Connections: 3 ft (.91 m) cable
Transmitter Enclosure Rating: Designed to meet NEMA 4X (IP66)
