HR1520 Professional Motherboard Short Circuit Tester 15V 20A Output Data An WGNJ:
$97.81
Feature:
1. [High Compatibility]: The new short circuit detector with 15V/3.2A output is suitable for most cell phones, computers, and other small devices. It can detect short circuit faults in the circuit board of any cellphone and laptop and meet the testing needs of different devices.
2. [Accurate Detection]: It can accurately and quickly assess the current interruption of the motherboard, helping technicians to make effective repairs. Equipped with a tiger clip, its flexible soft silicone cable can detect the short circuits within seconds, improving work efficiency.
3. [Intelligent Anti Burning]: Rear mounted seven-blade brushless silent small fan, strong wind power, efficient heat dissipation. Rear-mounted fuze, effectively preventing the machine from overheating and burning out, ensuring the service time of the equipment. Built-in high-frequency transformer, high-frequency voltage stabilization, saving energy consumption.
4. [Easy to Operate]: One-button setup, and quick adjustment of test data, making the work more convenient and . With an adjustment knob, long press the knob, you can enter the data adjustment mode; rotate the knob, and you can adjust the test parameters.
5. [Wide Applications]: Not only can be used for computers and their peripherals, automatic production line broadcasting equipment, and other high tech equipment voltage regulation, but also can be used for national defense, scientific research, laboratories in universities and colleges, charging equipment, such as direct current powersupply, as well as a variety of electronic equipment aging test.
Specification:
Specifications:
Name: Short Circuit Tester
Product model: HR-1520
Material: metal+plastics
Output voltage: 0-15VDC
Output current: 0-20A
Display: Multi-data digital display
Load stability: ≤0.01±2mv
Recovery time: ≤100us
Short circuit protections: Yes
Buzzer warning: Yes
Item size: 130 * 100 * 45mm / 5.12 * 3.94 * 1.77in
Item weight: 550g / 1.21lb
Package size: 255 * 165 * 75mm / 10.04 * 6.50 * 2.95in
Package weight: 1300g / 2.87lb
Package List:
1 * Short Circuit Tester
1 * Cable
1 * Test Clip
