DC 100A 100V Voltmeter Ammeter Volt Amp Meter Voltage Current Tester with Shunt For Sale

DC 100A 100V Voltmeter Ammeter Volt Amp Meter Voltage Current Tester with Shunt
When you click on links to various merchants on this site and make a purchase, this can result in this site earning a commission. Affiliate programs and affiliations include, but are not limited to, the eBay Partner Network.

Buy Now

DC 100A 100V Voltmeter Ammeter Volt Amp Meter Voltage Current Tester with Shunt:
$5.05

Monitor DC voltage and current at a glance with this compact dual digital voltmeter and ammeter. Featuring separate red and blue LED displays, it provides a clear view of electrical readings for a wide range of DC applications. The meter can measure voltage from 0–100V and is available in current measurement options of 10A, 50A or 100A, making it suitable for automotive projects, electrical testing, DIY electronics and other DC power systems.

Its compact 48 × 29 mm housing is designed for panel mounting, with a 45.5 × 26.5 mm mounting cutout. The bright 0.28-inch LED displays are easy to read, while the fast refresh rate allows you to monitor changing readings digital display for simultaneous voltage and current readings

  • Red and blue LED displays for easy identification of readings

  • Measures DC voltage from 0–100V

  • Available in 10A, 50A and 100A current measurement versions

  • 0.1V minimum voltage resolution

  • 0.01A minimum current resolution

  • Approx. 500 ms display refresh rate

  • Compact panel-mount design

  • Suitable for automotive, electrical and DIY applications

  • Operating temperature range from -10°C to Type: Digital Voltmeter Ammeter

  • Power Supply: DC

  • Operating Voltage: DC 4.5–30V

  • Voltage Measurement Range: DC 0–100V

  • Current Measurement: 10A / 50A / 100A

  • Accuracy: 1% ±1 digit

  • Display: Dual 3-Digit LED

  • Display Size: 0.28 inch

  • Display Colours: Red and Blue

  • Operating Current: Less than 20mA

  • Dimensions: Approx. 48 × 29 × 21 mm

  • Mounting Cutout: Approx. 45.5 × 26.5 mm

  • Operating Temperature: -10°C to 65°C

  • Operating Humidity: 10–80% RH, non-condensing

  • Battery: Not Included

    • Package Includes:

    • 1 x Dual Digital Voltmeter Ammeter

    • 1 x Current Shunt/Diverter where applicable to the selected version
