AEMC Instruments 6555 15Kv Megohmmeter Volt Meter Insulation Tester:
$3999.99

AEMC Instruments 6555 15Kv Megohmmeter Volt Meter Insulation Tester
w/ black separate bag with red electric charging cables

AEMC Instruments 6555 is a 15kV Megohmmeter and Voltmeter, designed for high-voltage insulation testing. It includes a black separate bag and red electric charging cables, providing portability and convenience for field use. Ideal for accurate, reliable electrical insulation resistance measurements.

The AEMC 6555 is a 15kV digital megohmmeter for insulation testing on motors, cables, and electrical apparatus. It supports fixed/variable voltage tests, step and ramp profiles, automatic DAR/PI/DD ratios, on-screen graphs, and USB/DataView reporting with storage for up to 80,000 points.

15kV Insulation Testing with Advanced Diagnostics

Built for high-voltage insulation resistance testing, the AEMC 6555 combines programmable test modes, on-instrument graphing, and robust data management for preventive maintenance and acceptance testing of electrical equipment. It operates from rechargeable batteries or AC power during testing and is housed in an IP54-rated enclosure when closed.

High-Voltage Insulation Resistance Testing

Test voltages up to 15,000 VDC with fixed and variable test options
Fixed test voltages: 500, 1000, 2500, 5000, 10,000, and 15,000 V
Variable voltage range: 40 V to 15 kV with user-programmable voltage schemes
Insulation resistance measurement ranges by test voltage (examples):
- 500 V: 10 kΩ to 2000 GΩ (2 TΩ)
- 10,000 V: 10 kΩ to 25,000 GΩ (25 TΩ)
- 15,000 V: 10 kΩ to 29,000 GΩ (29 TΩ)

Automated Test Modes and Trending Tools

Step mode: up to 10 steps (voltage + duration configurable)
Ramp mode: programmable start voltage, end voltage, and duration; ramp configuration supports up to 15,000 V
Built-in ratio calculations: DAR, PI, and DD
On-screen graphical views: R(t)+V(t), I(t), and I(V)
Four measurement filters to stabilize readings in difficult environments

Current Control, Leakage and Capacitance Measurements

Max test current: 5 mA, stop modes, including I-Limit and Early-Break options for sensitive components
Leakage current measurement: 0 to 10 mA
Capacitance measurement: 0.005 to 19.99 µF
Automatic discharge after test

Data Storage, USB Connectivity and Reporting

Internal memory stores 80,000 points (R, V, I with date)
Optically-isolated USB communication for safer PC connection
Works with DataView® software for data retrieval, analysis, graphs, and report generation
