NSK NN3020MBKRE44CC1P4 Hight Rigidity Double Row Cylindrical Roller Bearings For Sale

When you click on links to various merchants on this site and make a purchase, this can result in this site earning a commission. Affiliate programs and affiliations include, but are not limited to, the eBay Partner Network.

---

NSK NN3020MBKRE44CC1P4 Hight Rigidity Double Row Cylindrical Roller Bearings :
$330.00

NSK NN3020MBKRE44CC1 P4 HIGH RIGIDITY DOUBLE ROW CYLINDRICAL ROLLER BEARINGS. (TAPERED SERIES)

Brand: NSK

Type: NN: Double Row Cylindrical Roller Bearings withtriple-ribbed inner ring

Dimension symbol 30: 30 Series

Bore number 20: Bearing bore= bore number x 5mm

Cage Material MB: Roller guided machined brass cage

Tapered bore KR: 1/12 Tapered bore

Lubrication E44:Lubricationholes symbol

Radial clearance CC1: Standard clearance for tapered bore

Accuracy P4: ISO Class 4 ABEC – 7

Dynamic load Cr: 157,000 N

Static load Cor: 265,000N

Limiting speeds: Grease: 6,600 rpmOil: 7,900 rpm

Dimensions: 100mm x 150mm x37mm

Quantity: One bearing

Weight: 4lb 11oz

NOTE: These Bearings Made in Fujisawa Plan Japan byNSK ltd; For Asia Region Distribution, Not for US or EU Distribution.

The barcode on the box is used for inventorypurpose.

---

---

---
