NSK 7210CTRDULP4Y Abec-7 Super Precision Spindle Bearings. ( Set of Two ):
$195.00
NSK 7210CTRDULP4Y SUPER PRECISION ANGULAR CONTACT SPINDLE BEARINGS
Brand NSK
Type Angular Contact Ball Bearings
Contact angle C: 15 Degree
Cage symbolTR: Outer ring guided phenolic resin cage
Rings material Bearing steel (SUJ2)
Rolling elements materialBearing steel (SUJ2)
Arrangement DU: universal arrangement (Double row)
Accuracy rating P4Y: Special accuracy (Bore diameter and outsidediameter are
exclusive toNSK. All others are ISO Class 4.)
Limiting speeds Grease: 16,500 rpm Oil: 25,000 rpm
Dynamic load ratingCr: 45.0 KN
Static load rating Cor:31.50 KN
Limit axial load rating Cur: 21.10 KN
Dimensions 50mmx 90mm x 20mm
Quantity Twobearings
Made in Japan by NSK ltd.
THIS SET OF TWO NSK 7210CTRDULP4Y; REPLACES THE FOLLOWING:
NSK 7210CTYNDBLP4 NSK 7210CTYNSULP4 NSK 7210CTYNDUMP4 NSK 7210CDULP4
NACHI 7210CYDUP4 NACHI 7210CYDU/GLP4
FAG 7210 CT P4S DUL
SKF 7210CD/P4A SKF 7210CD/P4ADBA
FAFNIR 2MM210WI DUL
BARDEN 210HDL
RHP 7210CTDULP4
GMN S6210C TA A7 DUL
