flash/chase controller

Discuss about electronic circuits here. Request help for circuits that you couldn't find anywhere else, how a circuit works etc. Discuss anything related to electronic circuits.

Moderator: pebe

Post a reply

flash/chase controller

Postby sheldons » Mon Feb 18, 2013 9:39 pm

heres my latest controller schematics...the front end is based on a standard 4017 counter circuit ,this just shows the output stage and control logic
Attachments
led controller.jpg
led controller.jpg (85.17 KiB) Viewed 5679 times
sheldons

Posts: 6
Joined: Sun Feb 17, 2013 4:59 pm
